GC-1325ATC 2D 3D 3Axis 4Axis Wood Cutter Engraver Machine CNC Router1325 1530 2030 with Leadshine Servo Motor Driver
GC-1325ATC 2D 3D 3Axis 4Axis Wood Cutter Engraver Machine CNC Router1325 1530 2030 with Leadshine Servo Motor Driver

GC-1325ATC 2D 3D 3Axis 4Axis Wood Cutter Engraver Machine CNC Router1325 1530 2030 with Leadshine Servo Motor Driver

2 reviews / Write a review
$11,800.00
Brand: GoodCut
Product Code: GC-1325ATC
Availability: In Stock

GC-1325ATC 2D 3D 3Axis 4Axis Wood Cutter Engraver Machine CNC Router1325 1530 2030 with Leadshine Servo Motor Driver




1.Feature:

1) Whole machine is welded with seamless steel structure, which is high temperature annealing and vibrating stress relief, so the lathe body is stabilized and will not be deformed forever.

2) Three axes adopt Taiwan HIWIN linear guide rail with high precision. Z axis adopts imported Taiwan made ball screw, so high precision and long life time using are assured.

3) Yaskawa servo system and reducer to make sure speed and stability. YASKAWA servo motors runs smoothly, no vibration phenomenon even in low speed and has overload ability,servo is more reliable and better than stepper.

4)  X and Y axis is transmitted by helical rack and pinion. This makes the machine work faster and has larger cutting force compared with ball screw transmission.

5) Well compatibility: CAD/CAM designing software, such as type3/ucancam/artcam, etc.

6) This machine has the function of re-carving after break point or power failure and it can estimate the processing time.

7) Manual/automatic oil-injection system allows the machine maintenance mush easier.








2.Parameter:

Model
GC-1325ATC
Working area
1300*2500*200mm
Table size
1310*3000mm
XYZ travel positioning accuracy
±0.01mm
Transmission system X-Y axis
Helical gear rack + HIWIN Linear Rail
Transmission system Z axis
Double nut Ball screw
Spindle power
9.0KW HQD
Cooling method
Air cooling
Spindle speed
0-24000rmp
Max velocity
80m/min
Max working speed
50m/min
Driving system
Japan yaskawa 750w servo motor
Japan yaskawa driver
Working Voltage
3phase 380V
Command language
G code
Interface
USB or parallel port
Operating system
SYNTEC / SHANLONG / WEIHONG for option
X-Y resolution
<0.025mm
Software environment
Artcam
Running environment
Temperature:0-45℃
Packing size
3500*2200*2200mm
Weight
1700/2000kgs














3. Application:


1) Woodworking industry:
Solid wood furniture, custom furniture, furniture decoration, musical instrument manufacturing, wooden handicrafts, art models, artistic font characters, logos, plate plane carving, artistic murals, screen relief carving and cutting, decoration processing, gift packaging, wave boards, Cutting the three-dimensional surface and shape of various wooden industrial products such as electrical appliances, sporting goods, etc.
2) Mold industry:
It can engrave various molds, wooden molds, fonts, aviation wooden molds, propellers, building models, sand table models, motorboat models, automobile foam molds, etc.
3) Plate processing:
Insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate board,epoxy resin, ABS, PP, PE and other carbon mixed compounds.
4) Decorate industry:
Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.
5) Craft & gift industry:
Engrave various word or graph on the souvenir and handicraft, ironwork engraving, dials.
6) Advertising industry:
Engrave and cut various signboards, marble, copper, character mold, font. And various metal sign, brand.





GoodCut Service for 4x8 CNC Router with ATC System

1. In the processing of production, our professional technical engineers inspect the processing to ensure the quality of products.

2. Every ATC CNC machine must be tested before delivery for 72 hours, all of them are absolutely qualified.

3. 24 months guarantee of the whole machine.

4. Main parts (excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.

5. Lifetime maintenance free of charge.

6. We will provide the consumable parts at an agency price when you need replacement.

7. ATC CNC machine has been adjusted before delivery.
